What is Tesa 60218?
Tesa 60218 is a thick, grey single-sided conductive foam tape designed to deliver high-performance EMI shielding, grounding, and electrostatic discharge protection. With a highly compressible 2mm foam and conductive acrylic adhesive, it provides excellent performance in high-temperature and high-humidity environments while maintaining reliable cushioning and adhesion.
Composition and Structure
- Base material: Highly compressible conductive foam
- Adhesive system: Conductive acrylic adhesive
- Total thickness: 2000μm (2.0mm)
- Width: 1000mm
- Length: 40m
- Color: Grey
- Release paper type: PE coated paper
- Release paper thickness: 120μm
- Release paper color: White or blue trademark
- Surface resistance (X-Y direction): 0.2 mOhm
- Contact resistance (Z direction, initial): 0.03 Ohm/square inch
- Short-term temperature resistance: Up to 200°C
- Long-term temperature resistance: Up to 100°C
Key Properties
- High conductivity in XYZ directions
- Strong adhesion in harsh environments
- 2mm thick foam provides excellent impact resistance
- High conformability to surface irregularities
- Low closing force and reliable recovery
- Foam stability minimizes particle shedding
- Performs well in high temperature and high humidity
Applications of Tesa 60218
- EMI shielding and grounding for electronic devices
- Electrostatic discharge protection in sensitive assemblies
- Automotive electronics and component fixation
- Medical device safety and electrostatic control
- Appliance manufacturing for component bonding and safety
- Shock absorption and structural gap filling
Features & Benefits of Tesa 60218
- Extra-thick foam for enhanced shock absorption
- Excellent conductivity and long-term reliability
- Reduces electromagnetic interference and static buildup
- Adapts well to irregular or uneven surfaces
- Safe for use in sensitive medical and electronic equipment
- Maintains bonding performance in extreme conditions
Comparison with Other Adhesive Tapes
- Thicker than other conductive foam tapes like Tesa 60213 or 60214
- Offers enhanced cushioning and gap-filling capability
- Similar conductivity performance with increased structural support
- Ideal for heavy-duty or precision electronic environments
Why Choose VST Malaysia?
VST Malaysia delivers advanced adhesive solutions tailored for industrial, automotive, and electronic sectors. With our high-quality offerings like Tesa 60218, we ensure strong product performance, technical support, and on-time delivery for your most demanding applications.
